- Size: 3910*1230*2210
- Place of Origin: Shandong Qingzhou
- Brand Name: SWLTD
- Model Number: CPCY30
- Weight: 4300.000 kg
Parameter
Sequence | Category | Item | Unit | CPC30 Specification |
1 | Overview | Rated load | kg | 3000 |
2 | Load center distance | mm | 500 | |
3 | Standard dead weight | kg | 4300 | |
4 | Basic size | Machine size | mm | 3910*1230*2210 |
5 | Max lifting height | mm | 3000 | |
6 | Maximum height | mm | 4130 | |
7 | Fork | mm | 1070*130*45 | |
8 | Fork spacing (outside) | mm | 1155 | |
9 | Front overhang distance | mm | 473 | |
10 | Forward/rear tilting angel of mast | ° | 6/12 | |
11 | Min.Operating Radius | mm | 2510 | |
12 | Ground clearance | mm | 140 | |
13 | Performance | Max speed | km/h | 21 |
14 | Full load max lifting speed | mm | 490 | |
15 | Max climbing degree | mm | 20 | |
16 | Tires | Front wheel | 28×9-15-14PR | |
17 | Rear wheel | 6.50-10-10PR | ||
18 | Front wheel tread | mm | 1030 | |
19 | Rear wheel tread | mm | 974 | |
20 | Wheel base | mm | 1705 | |
21 | Battery | V/Ah | 12/80 | |
22 | Engine | Brand |
|
|
23 | Model | C490BPG | ||
24 | Rated power | kw/rpm | 40/2650 | |
25 | Rated torque | N·m/r·p·m | 148/1900 | |
26 | Number of cylinders | 个 | 4 | |
27 | Fuel tank capacity | L | 65 | |
28 | Pump | Pressure | 2540 | 16 |
29 | Transmission | Gear shift stage | 65 | 2/2 |
