Product Details
- Size: 4585*1700*2720
- Place of Origin: Shandong Qingzhou
- Brand Name: SWLTD
- Model Number: CPCY30
- Weight: 3268.000 kg
Parameter
| Serial number | Project | Unit | Parameter | Note | |
| 1 | Rated load | （KG) | 3000 | ||
| 2 | Load center | mm | 565 | ||
| 3 | Ascent | mm | 3000 | ||
| 4 | The freedom lifts the altitude | mm | 150 | ||
| 5 | Gate incline front/after | （°） | 6/12 | ||
| 6 | Lifts most greatly the intensity(full load) | mm/s | 372 | ||
| 7 | Running rate | Advance:ⅠFiles/IIFiles | km/h | 8/16 | |
| 8 | Backlash:ⅠFiles/IIFiles | km/h | 8/16 | ||
| 9 | Biggest climbing power (full load) | % | 50 | ||
| 10 | Biggest force of traction | （Kgf) | 2587 | ||
| 11 | Biggest deflection angle | （°） | ±35 | ||
| 12 | Rear axle of car angle of oscillation | （°） | ±12 | ||
| 13 | Most steep bank radius | mm | 4500 | ||
| 14 | External dimensions | External dimensions | mm | 4585 | Belt tooth |
| 15 | Width | mm | 1700 | ||
| 16 | Height | mm | 2720 | ||
| 17 | Smallest ground clearance | mm | 260 | ||
| 18 | Dead weight | Kg | 3268 | ||
