Product Details
- Size: 6660*2620*3520
- Place of Origin: Shandong Qingzhou
- Brand Name: SWLTD
- Model Number: CPCY100
- Weight: 14500.000 kg
Parameter
| Sequence | Item | Unit | Specification | |
| 1 | Rated load | kg | 10000 | |
| 2 | Length | No fork | mm | 5300 |
| With fork | mm | 6660 | ||
| 3 | Width | mm | 2620 | |
| 4 | Height | Height of the mast | mm | 3040 |
| Height of the cab | mm | 3520 | ||
| Full height whem max lifting | mm | 4530 | ||
| 5 | Wheelbase | mm | 2730 | |
| 6 | Front overhang distance | mm | 930 | |
| 7 | Front wheel tread | mm | 1917 | |
| 8 | Rear wheel tread | mm | 1805 | |
| 9 | Ground clearance | mm | 400 | |
| 10 | Max lifting height | mm | 3000 | |
| 11 | Free lifting height | mm | - | |
| 12 | Forward / rear titling angle of mast | (°) | 6/12 | |
| 13 | Standard Dead weight(no-load) | kg | 14500 | |
| 14 | Full load Max lifting speed | mm/s | 187 | |
| 15 | Min turning radius | mm | 5500 | |
| 16 | Max speed | km/h | 24 | |
| 17 | Max clinbing degree(full load) | % | 20 | |
| 18 | Max Drawbar(full load) | kN | 75 | |
| 19 | Load center distance | mm | 600 | |
